中文COVIDIEN EEA™ TRIEEA(XL)33/31/28MT/XT Circular Stapler
COVIDIEN EEA™ Circular Stapler TRIEEA28MT,TRIEEA28XT,TRIEEA31MT,TRIEEA31XT,TRIEEAXL33MT,TRIEEAXL33XT
Phone：+86-21-54286005
Resources
TRIEEA-eea_Brochure-EN
TRIEEA-eea_Brochure-EN
360-DEGREE STAPLE LINE SECURITY.
FOR ALL AROUND CONFIDENCE.
EEA™ Circular Stapler with Tri-Staple™ Technology
EASIER TO FIRE.
EASIER TO HEAR AND FEEL WHEN YOU DO.
Three rows of varied height staples6
Same inner and outer lumen diameters as circular staplers with DST Series™ technology6
Tilt-top™ anvil facilitates removal
Better audible and tactile feedback9,†,‡
†Compared to two-row circular staplers.
‡16 out of 19 surgeons surveyed agreed.
The EEA™ circular stapler with Tri-Staple™ technology has a sloped cartridge face.
The EEA™ stapler with DST Series™ technology and the Ethicon™* ILS stapler each have a flat cartridge face.
The Tri-Staple™ technology’s sloped cartridge face delivers less stress on tissue compared to the Ethicon™* ILS stapler’s flat-faced cartridges during compression and clamping.11,†,§
SLOPED CARTRIDGE FACE FLAT CARTRIDGE FACE
†Compared to two-row circular staplers. ‡Preclinical results may not correlate with clinical performance in
humans. §Finite element analysis (FEA) was used to determine the strain profiles of three circular staplers
during clamp-up. The EEA™ circular stapler with Tri-Staple™ technology demonstrated a graduated
compression profile upon clamping.
STAPLE HEIGHT
RECOMMENDATIONS
EEA™ circular stapler with Tri-Staple™ technology
If you normally use a 4.8 mm green thick tissue circular stapler, or larger,for anastomosis, then you should consider converting to the black extra-thick EEA™ circular stapler with Tri-Staple™ technology.
The black stapler provides an approximate staple height of 4.0 mm, 4.5 mm,and 5.0 mm.
If you normally use a 4.8 mm green thick tissue circular stapler, or larger, for anastomosis,but the patient’s tissue
seems thinner than the indicated range,you should consider converting to the purple medium/thick EEA™ circular stapler with Tri-Staple™ technology.
The purple stapler provides an approximate staple height of 3.0 mm,3.5 mm, and 4.0 mm.
If a black extra-thick EEA™ circular stapler with Tri-Staple™ technology is not available, and the tissue exceeds the indicated range of either a 3.5 mm blue circular stapler or the purple medium/thick circular stapler, then you should consider using a 4.8 mm green thick tissue circular stapler with DST Series™ technology.
Order Information
| ORDER CODE | DESCRIPTION | COLOR | STAPLE SIZE (INNER TO OUTER ROW) |
UNIT OF MEASURE |
QUANTITY |
|---|---|---|---|---|---|
| TRIEEA28MT | EEA™ Circular Staple with Tri-Staple™ Technolog 28 mm Medium/Thick | Purple | 3.0 mm, 3.5 mm, 4.0 mm | Box | 3 |
| TRIEEA28XT | EEA™ Black Circular Staple with Tri-Staple™ Technolog 28 mm Extra Thick | Black | 4.0 mm, 4.5 mm, 5.0 mm | Box | 3 |
| TRIEEAXL28MT | EEA™ Circular Stapler with Tri-Staple™ Technology 28 mm Medium/Thick XL | Purple | 3.0 mm, 3.5 mm, 4.0 mm | Box | 3 |
| TRIEEAXL28XT | EEA™ Black Circular Stapler with Tri-Staple™ Technology 28 mm Extra Thick XL | Black | 4.0 mm, 4.5 mm, 5.0 mm | Box | 3 |
| TRIEEA31MT | EEA™ Circular Stapler with Tri-Staple™ Technology 31 mm Medium/Thick | Purple | 3.0 mm, 3.5 mm, 4.0 mm | Box | 3 |
| TRIEEA31XT | EEA™ Black Circular Stapler with Tri-Staple™ Technology 31 mm Extra Thick | Black | 4.0 mm, 4.5 mm, 5.0 mm | Box | 3 |
| TRIEEAXL31MT | EEA™ Circular Stapler with Tri-Staple™ Technology 31 mm Medium/Thick XL | Purple | 3.0 mm, 3.5 mm, 4.0 mm | Box | 3 |
| TRIEEAXL31XT | EEA™ Black Circular Stapler with Tri-Staple™ Technology 31 mm Extra Thick XL | Black | 4.0 mm, 4.5 mm, 5.0 mm | Box | 3 |
